제품 소개집의 배터리 저장

0℃~55℃ Charge -20℃~60℃ Discharge 10.24kWh LiFePO4 Wall Battery All Climate Solar Storage

제가 지금 온라인 채팅 해요

0℃~55℃ Charge -20℃~60℃ Discharge 10.24kWh LiFePO4 Wall Battery All Climate Solar Storage

0℃~55℃ Charge -20℃~60℃ Discharge 10.24kWh LiFePO4 Wall Battery All Climate Solar Storage
0℃~55℃ Charge -20℃~60℃ Discharge 10.24kWh LiFePO4 Wall Battery All Climate Solar Storage

큰 이미지 :  0℃~55℃ Charge -20℃~60℃ Discharge 10.24kWh LiFePO4 Wall Battery All Climate Solar Storage

제품 상세 정보:
원래 장소: 중국
인증: CE ISO
모델 번호: KM 48V 100Ah
결제 및 배송 조건:
최소 주문 수량: 1
가격: USD1-100/pcs
포장 세부 사항: 표준 국제 판지 포장
배달 시간: 일반 2주, 정확한 수량에 따라 수량 추가
공급 능력: 10000pcs/월

0℃~55℃ Charge -20℃~60℃ Discharge 10.24kWh LiFePO4 Wall Battery All Climate Solar Storage

설명
공칭 전압: 48V 최대 충전 전류: 200A
공칭 용량: 200Ah 배터리 크기: 618*480*248mm
공칭 에너지: 10240Wh 순중량: 85KG
세포 유형: lifepo4 셀 표준 충전 전류: 100A
방전용 컷오프 전압: 56.2V 최대 연속적인 방전 전류: 200A
방전 전류: 10A 단말기: 빠른 플러그인
강조하다:

10.24kWh LiFePO4 wall battery

,

all climate solar storage battery

,

home battery storage with warranty

0℃~55℃ Charge -20℃~60℃ Discharge 10.24kWh LiFePO4 Wall Battery All Climate Solar Storage
Our 48V200P2 wall-mount lithium iron phosphate battery is the best-selling residential solar energy storage unit of 2024, built with premium EVE A-grade prismatic LiFePO4 cells and a built-in 100A intelligent BMS system. Delivering 10240Wh usable power, this ultra-thin powerwall perfectly matches off-grid, hybrid solar systems and diesel generator backup power supply, fully meeting 10kW household electricity demand. Certified with CE, RoHS, UL, UN38.3 and IEC safety standards, it supports over 8000 deep charge-discharge cycles and comes with an industry-leading 10-year full warranty for global residential users.
Key Features
  • Grade A Quality: KM exclusively uses 100% grade A qualified LiFePO4 cells from leading brands including EVE, CATL, BYD, or Gotion. Each cell features original QR code and guaranteed 100% capacity, ensuring optimal cycling life and operational performance.
  • Comprehensive BMS Protection: Built with top-level intelligent Battery Management System that protects against short-circuit, overcharging, over-discharging, over-current, and other hazardous conditions, ensuring safety and extended working life.
  • Competitive Pricing: KOUMAN, as a 10-year developed lithium battery manufacturer with strategic partnerships with material suppliers, offers unbeatable prices to support customer growth and business expansion.
KM 48V 200Ah LiFePO4 Wall Battery product image
Technical Specifications

Specification Details
Product Model KM48V200R
Nominal Voltage 51.2V
Nominal Capacity 200Ah
Nominal Energy 10240Wh
Cell Type LiFePO4 Cell
Standard Charging Current 100A
Max Charging Current 200A
Discharging Cut-off Voltage 56.2V
Max Continuous Discharging Current 200A
Discharging Current 10A
BMS Protection Overcharging/over-discharging, Over-voltage/Over-current, Short Circuit, etc.
Case Material Metal/Custom material
Terminal Fast plug-in
Battery Size 618*480*248mm
Net Weight 85kg
Communication CAN/RS485/RS232/Bluetooth (optional)
Shipping Method Sea/Air/Railway
Delivery Time Quantity within 100pcs: 5-12 days
Additional models available: 300Ah, 200Ah, 150Ah, 280Ah, 50Ah, 25Ah configurations.0℃~55℃ Charge -20℃~60℃ Discharge 10.24kWh LiFePO4 Wall Battery All Climate Solar Storage

FAQ

Q1: What devices can this 51.2V 200Ah battery charge?

A: It works with solar panel arrays, diesel generators and municipal grid power. It supplies stable backup power for home refrigerators, air conditioners, lights, water pumps and essential household loads up to 10kW total power demand. Compatible with most mainstream 48V solar hybrid inverters.

Q2: How many charge cycles can this battery support?

A: Our EVE A-grade LiFePO4 cell design delivers more than 8000 deep discharge cycles, equivalent to over 10 years of daily regular use, much longer than lead-acid or low-grade lithium batteries.

Q3: Is this wall battery safe for indoor home installation?

A: Yes. LiFePO4 material features extremely low thermal runaway risk, plus built-in intelligent BMS with full overcharge/short-circuit/temperature protection. It holds CE, UL, RoHS global safety certifications, safe for bedroom, garage and utility room wall mounting.

Q4: Can multiple AK-48V200P2 batteries be connected in parallel?

A: Yes. Multiple units can be parallel connected to expand total storage capacity and power output. Optional CAN/RS485 communication ports realize unified battery monitoring for the whole battery bank.

Q5: What’s the operating temperature range?

A: Charging environment: 0℃ ~ 55℃; Discharging environment: -20℃ ~ 60℃. It can stably supply power in cold winter areas and hot tropical regions.
